    Parallel IEEE 1284 Printer Cable Centronics-36 Male To Centronics-36 Male

    Ask Lasest Price
    Brand Name : FUYCONN
    Model Number : FUY57CABLE070
    Certification : ISO
    Price : Negotiable
    Payment Terms : T/T
    Delivery Time : 2-4 weeks
    • Product Details
    • Company Profile

    Parallel IEEE 1284 Printer Cable Centronics-36 Male To Centronics-36 Male

    Parallel IEEE 1284 Printer Cable Centronics-36 Male to Centronics-36 Male 36-Conductor Printer Cable CN36 Parallel Printer Cable


    SCSI cables are constructed to meet or exceed ANSI SCSI II, SCSI III and FAST SCSI ( Ultra SCSI ) specifications. These specifications define the SCSI cable, connector, and backshell operational characteristics for all external assemblies.
    Small Computer System Interface. The SCSI cables can also be known as a scuzzy cable. SCSI cable assemblies have either male to male, male to female or female to female connection configurations.
    Internal SCSI cables are constructed for either single ended or differential applications. For applications requiring 50 conductor flat cable ( 0.050 centers ) PVC meets ULTRA SCSI requirements. For applications requiring 68 conductor ( 0.025 centers ) TPE meets Ultra SCSI requirements. Ultra SCSI cables are downward compatible with SCSI II applications.
    SCSI Cable assembly with high density connector with 1.27mm (0.050-inch) spacing Conforms to the American national standards institute (ANSI) specification Choice of bracket configurations includes: latch only or without rails and latch All plastic type available in 14, 20, 26, 36, 50, 50, 68,100 positions Insulator is made of polyester resin and glass fiber reinforced (UL 94-0) providing superior heat and chemical resistance Application to miniaturized electronic equipments.

    SCSI Connector
    Product Features
    1. Product Line:
    Centronic Connector
    2. Product Name
    57 Connector
    3. Product Type
    Printer Connector
    4. Connector Gender:
    Male-Male
    5. Number of Position:
    36P-36P
    6. Contact Material:
    Phosphore Bronze
    7. Contact Plating:
    1U", 3U", 5U", 10U", 15U",30U"
    8. Insulation Material:
    PBT
    9. Color:
    Black
    9. Housing:
    180 degree Plastic Housing
    10. Connector Type
    Solder Cup
    11. Pitch
    2.16mm

    Data Sheet

    • Application

    SCSI cables are used to establish high-speed connections and enable data transfers between small computers and peripherals like printers, optical disks and hard disks. The assemblies have moulded covers, which ensure stable connections between devices. Used is dependent on where the SCSI bus is located on the device.
    SCSI cables are used in numerous applications including audio video, networking and telecommunications. Some SCSI cables are specifically designed for usage in high-vibration environments like industrial factories or manufacturing plants. SCSI cables are also used for AXA and SATA disk drives.
